Lewitt DTP 640 REX Dual-Element Bass Drum Microphone

Lewitt DTP 640 REX Dual-Element Bass Drum Microphone (DTP-640 REX / DTP640REX)

---

The DTP 640 REX Dual-Element Bass Drum Microphone from Lewitt incorporates both dynamic, and back-electret condenser elements to provide a full-bodied low-frequency audio quality well suited for kick drums, percussion, bass guitar cabinets, woodwinds and other instruments. The dynamic element effectively captures the punch, while the condenser element captures the detail, warmth and tonal quality of the instrument. The cardioid polar pattern minimizes off-axis feedback and noise.

---

FEATURES

• Dual-element instrument microphone
• Dynamic and condenser capsule in one housing
• Separate outputs for both capsules
• For kick drum and other bass-heavy sources
• Three switchable sound characteristics
• Cardioid polar pattern

---

SPECIFICATIONS

• Type : Dynamic, moving coil, Condenser, permanently polarized
• Acoustical operating principle : Pressure gradient transducer
• Transducer Ø : 31.7 mm, 1.25 in
• Transducer Ø : 22.4 mm, 0.88 in
• Polar pattern : Cardioid
• Frequency range (dynamic) : 20 ... 16,000 Hz
• Frequency range (condenser) : 20 ... 20,000 Hz
• EFR, ‘Enhanced Frequency Response' settings
• Sensitivity, = // = FFR : 0.4 mV/Pa (-69 dBV), dynamic | 2 mV/Pa (-54 dBV), condenser
• Sensitivity, + // = Dynamic EFR : 0.4 mV/Pa, -69 dBV/Pa, dynamic | 2 mV/Pa, -54 dBV/Pa, condenser
• Sensitivity, + // + Dual EFR : Condenser and dynamic matched at 1 mV/Pa, -60 dBV
• Equivalent noise level : 28 dB (A)
• Max. SPL for 0.5 % THD : 150 dBSPL, 0 dB pre-attenuation
• Dynamic range of mic. amp. (condenser) : 122 dB
• Pre-attenuation pad : 0 dB | -10 dB | -20 dB
• Rated impedance dynamic : 500 Ω
• Rated impedance condenser : 200 Ω
• Supply voltage : 48 V ± 4 V
• Current consumption : 2 mA
• Connector : Gold plated 3-pin and 5-pin XLR
• Cable : 1.5 m (4.95’) dual shielded Y-cable, 5-pin XLR into two 3-pin XLRs
• Microphone dimensions : 71 dia. x 158 mm, 2.8 dia. x 6.2 in
• Microphone net weight : 755 g, 27.3 oz

---
