Yamaha DBR12 800-watt Powered Speaker

Yamaha DBR12 800-watt Powered Speaker (DBR-12)

---

Able to withstand a whopping 131dB SPL, the Yamaha DBR12 12" active speaker gives you an accurate, controlled performance. Using the latest DSP, Yamaha applied their proprietary FIR-X tuning to optimize the sound and protection algorithms of the DBR12, providing you with plenty of muscle, despite this active speaker's rather diminutive size. Incredibly versatile, you can use the DBR12 as a great-sounding main speaker or as a high-performance floor monitor with a quick flick of the Yamaha DBR12 12" active speaker's D-Contour switch. A switchable highpass filter also makes it easy for you to add a subwoofer to your rig. Music Bliss has put together countless live systems over the past three decades, so give us a call. We'll be glad to help you out!

---

FEATURES

• FIR-X tuning delivers excellent sound quality with high resolution and a smooth frequency response
• D-Contour optimizes the DBR12 for main speaker or floor monitor use
• Onboard mixer lets you select either a direct output or a mixed output
• Comprehensive inputs for mixer, musical instrument, or media players
• Amplifier and power supply design provides powerful output from a compact speaker
• DSP-controlled protection functionality promotes optimum reliability

---

SPECIFICATIONS

• Powered:Yes
• Power Configuration:Bi-amped
• LF Driver Size:1 x 12"
• HF Driver Size:1.4"
• LF Driver Power Amp:800W
• HF Driver Power Amp:200W
• Total Power:1000W
• Inputs:2 x XLR/TRS Combo, 1 x Stereo
• Outputs:1 x XLR
• Frequency Range:52Hz-20kHz (-10dB)
• Crossover Frequency:2.1kHz
• Maximum Peak SPL:131dB
• Horizontal Coverage Angle:90 Degrees
• Vertical Coverage Angle:60 Degrees
• Enclosure Material:Plastic
• Mounting Options:Pole Mount with 1.37" socket, Floor Wedge, 3 x M8 Fly Points
• Height:23.7"
• Width:14.8"
• Depth:13.7"
• Weight:34.8 lbs.
• Manufacturer Part Number:DBR12
